| 压力检测 / Pressure Detection | 正压、负压双指示指针压力表一个（可选数字真空计等） / One dual-indication pointer pressure gauge for positive/negative pressure (Optional digital vacuum gauge, etc.) |
| 气体流量计 / Gas Flow Meters | 两个浮球流量计（客户要求精度更高时可选数字质量流量计） / Two float flowmeters (Optional digital mass flowmeters for higher accuracy per customer request) |
| 压力保护 / Pressure Protection | 为了防止炉膛排气口关闭，排气口堵塞，炉膛压力过大产生危险，特别设计此系统。原理：由电接点压力表或者压力传感器获得信号，驱动控制模块关闭电磁进气阀，启动电磁排气阀和报警器，使压力从排气口释放，并触发报警器报警。从而保护电炉的正常运行 / To prevent hazards from closed furnace exhaust port, blocked exhaust, or excessive furnace pressure, this system is specially designed. Principle: A signal from an electric contact pressure gauge or pressure sensor drives the control module to close the solenoid intake valve, activate the solenoid exhaust valve and alarm, releasing pressure from the exhaust port and sounding the alarm. This protects the furnace's normal operation. |
| 气体泄漏报警 / Gas Leak Alarm | 根据所选用气体，避免发生泄漏；作用：气体泄漏报警控制器检测室内空气中的管路、危险性等气体的浓度超过一定值时，驱动模块关闭电炉，关闭气源进气，开启排气口、排风等，从而获得更高、更安全的工作环境。（需客户选择） / Depending on the gas used, to prevent leaks: When the gas leak alarm controller detects the concentration of dangerous gases in the indoor air from pipelines, etc., exceeds a set value, it drives the module to shut down the furnace, close the gas intake, open the exhaust port and ventilation, etc., creating a safer working environment. (Customer optional) |
| 可使用气体 / Usable Gases | 氧气、氮气、氩气、氢气、二氧化碳等等 / Oxygen, Nitrogen, Argon, Hydrogen, Carbon Dioxide, etc. |
| 耐火材料 / Refractory Material | 炉体使用采用进口德国MESCHUPP真空成型高纯氧化铝纤维轻质板材料，取样物料承压板（炉底）采用高纯轻质空心氧化铝板，使用温度高，蓄热量小，耐急冷急热，不裂缝，不粉化，保温性能好（节能效果是老式电炉的80%以上） / Furnace body uses imported German MESCHUPP vacuum-formed high-purity alumina fiber lightweight board. The material support plate (furnace bottom) uses high-purity lightweight hollow alumina board, featuring high service temperature, low heat storage, resistance to thermal shock, no cracking, no powdering, and good insulation (Energy saving effect is over 80% compared to old furnaces). |
| 保温材料 / Insulation Material | 采用四层保温，分别为：氧化铝纤维毯、氧化铝纤维板、氧化铝多晶纤维板，进口材料，节能效果是老式电炉的80%以上。 / Four-layer insulation, consisting of: alumina fiber blanket, alumina fiber board, alumina polycrystalline fiber board. Imported materials. Energy saving effect is over 80% compared to old furnaces. |
| 炉体外壳温度 / Furnace Shell Temperature | 长期使用不烫手，外壳温度不大于45度 / Low external temperature during long-term use, shell temperature ≤ 45°C |
| 保护 / Protection | 采用集成化模块控制单元，控制精度准确，并设计了双回路控制和双回路保护，具备了缺相、超调、欠调、断偶、换相、超压、超流、超温、电流反馈、软启动等保护 / Integrated modular control unit ensures accurate control. Features dual-loop control and dual-loop protection, including phase loss, overshoot, undershoot, thermocouple break, phase reversal, over-voltage, over-current, over-temperature, current feedback, soft start protections, etc. |
| 控制 / Control | 采用闭环技术可控硅模块触发控制，控制模块触发控制使输出电压、电流或功率平滑跟随设定曲线，具有恒电压、恒电流或恒功率的特性，电流为内环，电压或功率为外环，在实现负载电压或负载电流超过额定值时，限制调整管的输出电流在额定电流范围内，确保发热元件正常工作；同时电压或功率参与调节，使调压器的输出电流被限制在额定电流范围内，在有余量调节余量的前提下维持输出电流及电压或功率的恒定，从而达到保护发热元件避免过大电流、电压的冲击，达到安全可靠的控制效果及控制精度，详见电炉说明书 / Uses closed-loop technology with thyristor module trigger control. This control method allows the output voltage/current or power to smoothly follow the set curve. It has constant voltage, constant current, or constant power characteristics. Current serves as the inner loop, voltage/power as the outer loop. When the load voltage or current exceeds the rated value, it limits the output current to within the rated range, ensuring normal operation of the heating elements. Simultaneously, voltage/power participates in regulation, limiting the output current of the voltage regulator within the rated range, maintaining constant output current and voltage/power when sufficient regulation margin exists. This protects heating elements from excessive current/voltage impact, achieving safe, reliable control and high accuracy. See furnace manual for details. |
| 显示参数 / Display Parameters | 温度、温度段号、段时间、剩余时间、输出功率百分比、电压、电流等 / Temperature, temperature segment number, segment time, remaining time, output power percentage, voltage, current, etc. |
| 按钮 / Buttons | 采用高品质按钮使用寿命超过100000次，并且增加指示灯。 / High-quality buttons with lifespan over 100,000 cycles, with added indicator lights. |
| 温度曲线设定 / Temperature Curve Setting | 采用智能温度控制仪，备标准PID、人工智能调节AI-PID等多种调节方式，具有自整定、自学习功能，无超调及无欠调的优良控制特性，具备30段程序控制功能，可实现任意斜率的升降控制，具有跳转（循环）、运行、暂停及停止等可编程可操作命令，并允许在程序的控制运行中随时修改程序，采用具备曲线平滑功能的人工智能调节算法，能获得无需人工干预的平滑控制效果，详见电炉说明书 / Uses intelligent temperature controller with standard PID, artificial intelligence调节 AI-PID, and other modes. Features self-tuning, self-learning function, excellent control characteristics with no overshoot/undershoot. 30-segment program control function allows arbitrary heating/cooling rate setting. Includes programmable commands like jump (loop), run, pause, stop. Allows program modification during operation. Uses AI algorithm with curve smoothing function for smooth control effect without manual intervention. See furnace manual for details. |
| 多条曲线输入 / Multi-curve Input | 30段（可定制50段）程序控制功能，可以输入设定：一条曲线为30段，两条曲线14段/条，三条曲线10段/条，五条曲线6段/条；可同时输入多条曲线，使用时可任意调用。 / 30-segment (customizable to 50 segments) program control function. Setting examples: one curve with 30 segments; two curves with 14 segments each; three curves with 10 segments each; five curves with 6 segments each. Multiple curves can be input simultaneously and called arbitrarily during use. |
